Overview

Basic Info.

Model NO.	hollow glass
Shape	Flat
Appearance	Flat Tempered
Standard	GB/T 9963-1998
Steel Degree	Tempered Glass
Thickness of Flat Tempered Glass	3mm-19mm
Thickness of Curve Tempered Glass	3mm-19mm
Fragment State	I
Technics	Physically Tempered
Flatness	High Class
Usage	Building, Furniture, Electronics & Instruments, Auto Manufacturing, Daily Products, Courtyard School Supermarket Workshop Be
Product Name	Tempered Glass
Material	Glass
Color	Customized Color
Application	Courtyard School Supermarket Workshop
Thickness	3mm-19mm
Size	Customized Size
Packaging	Wooden Box
Feature	Clear/Safety/Toughened
Transport Package	Packed in Wooden Cases
Trademark	HangXing
Origin	China
Production Capacity	5000pieces/Week

Product Description

nsulating glass, also called insulated glass, are sealed units. It refers to two or more lites of glass glazed along the edges with spacers. The composed glass could be monolithic, or laminated glass, with or without coatings ( low e coating as typical). There are types of spacers available, such as stainless steel, aluminum, warm edge spacers in various colors. The space between the glass is sometimes filled with noble gas, such as argon or krypton. 90% filled, which is more helpful to reduce energy consuming. The most common architectural insulating glass unit configuration is 1/4" glass, 1/2" air space and 1/4" glass. We always call it double glazed glass units, triple glazed glass units for its processing way, or sometimes it is called as double pane glass, or triple pane glass panels. Commonly referred to as an "IGU," insulating glass is the most effective way to reduce air-to-air heat transfer through the glazing. When used in conjunction with low-E or reflective glass coatings, IGUs become an effective means to save energy.

Product Description

Glass Type	Insulating Glass
Double Glass Thickness	3mm+6A+3mm,5mm+6A+5mm, 6mm+9A+6mm, 6mm+12A+6mm, 6mm+16A+6mm,etc. 3mm+6Ar+3mm,5mm+6Ar+5mm, 6mm+9Ar+6mm, 6mm+12Ar+6mm, 6mm+16Ar+6mm,etc.
Glass Combination Type	Tempered Insulating glass, Laminated Insulating Glass, Low-e Insulating Glass, Frosted Insulating Glass, Silkscreen Printing Insulating Glass, Digital Printed Insulating Glass, Chrome Privacy Insulated Glass,etc.
Low E Type	Double silver low e, triple silver low e, online hard coated low e: Vitro Solarban 60, Solarban 70, Guardian SN54 SN68 SN62/27, Saint Gobain low e and so on
Spacer Options	Stainless steel, aluminum, TGI( warm spacer) , super spacer
Spacer Thickness	6mm, 9mm, 12mm, 16mm, 19mm(1/4'',11/32'',1/2'',9/16'',19/32'',5/8'')etc.
Gas Filling	Air, Argon, Krypton,etc
Glass Color Option	Clear, Low Iron, Super White, Super Clear, Extra White, Starphire, Optiwhite, Euro Grey, Dark Grey, Crystal Grey, Brown, Bronze, Ocean Blue, Ford Blue, Dark Blue,etc.
Size	Custom Sizes, Max: 18000mm L*3660mm H(Flat), 3300x8000mm(Curved or Bent)
Edge Processing	Flat Edge, Seamed Edge, Polished Edge, Bevelled edge, Flat Polished Edge, Round Edge
Irregular Shape	Rectangular, Round, Oval, Trapezoid, Parallel, etc. All edges can be bright polished.
Hole & Notch Available	Countersunk holes, round holes, bell-mouth holes, simple notch, mickey ears cutouts, etc. The edge of hole and notch can be polished by CNC
Trade Terms	EXW, FOB, CIF, DDU,etc
Lead Time	Generally 2-4 weeks, depend on order quantity.
Terms of Payment	30% down payment before production, 70% balance TT at shipment; L/C
MOQ	To be discussed
